Description
122cm x 244cm PVC Foam Board Printing – Full Sheet, No Joins, UV Printed
Full-Sheet Printed Foam Boards in 8×4 Format
Printed Today produces full-sheet 122cm x 244cm PVC foam board printing for contractors, sign installers, retailers and exhibition builders who need genuine large-format coverage from a single panel. This is the biggest board we cut, and the reason customers specify it is simple: one sheet means no seam. A hoarding run built from four full sheets shows three joins. The same run built from A1 panels shows dozens.
Our full-sheet printed foam board is UV printed direct to the substrate across the entire 244cm span in one pass. Consequently, colour density holds from corner to corner rather than drifting between separately printed panels — which is exactly the failure mode that makes tiled signage look amateur from twenty feet away.
Large-format foam core board printing on rigid PVC gives you a panel that is light enough for two people to lift onto a hoarding, yet stiff enough to span its full width without a supporting frame. For site boards, retail fascias, exhibition walls and event backdrops, the 8×4 sheet is the industry default for good reason.
The Full-Sheet Dimensions, in Every Unit
Different trades specify this board differently, so here is the same panel expressed five ways. All refer to one identical full sheet.
| Unit convention | Dimensions | Commonly used by |
|---|---|---|
| Imperial shorthand | 8×4 / 4ft x 8ft | Construction, sign trade, hoarding contractors |
| Feet | 4ft x 8ft | Site specification, materials ordering |
| Inches | 48in x 96in | Print and fabrication specification |
| Centimetres | 122cm x 244cm | Retail and exhibition briefs |
| Millimetres | 1220mm x 2440mm | Architectural drawings, CAD files |
| Area | 32 sq ft (2.97 m²) | Pricing and material calculation |
Choosing Between 5mm and 3mm Full-Sheet Foam Board
Both thicknesses print identically. The difference is structural, and at full-sheet scale it matters considerably more than it does at A3.
- 5mm PVC foam board — the default specification for 122cm x 244cm. At full-sheet width, 5mm holds itself flat across the span without bowing, which is why it is the correct choice for hoarding panels, shop fascias, freestanding displays and any board fixed only at its edges. Also the right call for exterior use, where wind loading across 32 sq ft is substantial.
- 3mm PVC foam board — around 15% cheaper and noticeably lighter, making it the sensible option where the sheet will be fully bonded to a backing wall, mounted inside a frame, or used indoors in a sheltered position. Two people handle a 3mm full sheet far more easily than a 5mm one. However, unsupported across its full width in an exposed position, 3mm will flex where 5mm will not.
In practice, most exterior and freestanding full-sheet work specifies 5mm, while interior wall-bonded and framed applications take 3mm and pocket the saving.
Full-Sheet Foam Board Prices
A 122cm x 244cm sheet covers 32 sq ft, which lands in a substantially cheaper per-sq-ft band than any A-size board. The full sheet is therefore the most economical way to buy foam board printing by area — around £2.82 per sq ft against roughly £8.95 at A4.
Single Full Sheet — 5mm and 3mm
| Delivery service | 5mm full sheet | 3mm full sheet | You save on 3mm |
|---|---|---|---|
| Standard — 5 working days | £90.24 | £76.70 | £13.54 |
| 72 hour | £108.29 | £92.05 | £16.24 |
| 48 hour | £121.82 | £103.55 | £18.27 |
| 24 hour | £148.90 | £126.57 | £22.33 |
| Same-day collection | £180.48 | £153.41 | £27.07 |
Single-sided, unlaminated. Double-sided UV printing adds 15%; matt or gloss lamination adds 10%.
Why Multiple Full Sheets Get Cheaper Fast
Because rates band by total order area rather than per board, full sheets drop into lower bands almost immediately. One sheet is already 32 sq ft, so two sheets clear 64 sq ft and three exceed 96 sq ft — meaning a hoarding run reaches the cheapest bands in a way that A-size orders rarely do.
| Sheets | Total area | Rate (5mm) | Total | Per sheet |
|---|---|---|---|---|
| 1 | 32 sq ft | £2.82 | £90.24 | £90.24 |
| 2 | 64 sq ft | £2.71 | £173.44 | £86.72 |
| 3 | 96 sq ft | £2.57 | £246.72 | £82.24 |
| 4 | 128 sq ft | £2.56 | £327.68 | £81.92 |
| 6 | 192 sq ft | £2.53 | £485.76 | £80.96 |
| 10 | 320 sq ft | £2.51 | £803.20 | £80.32 |
Deduct 15% throughout for 3mm. Ordering a full hoarding requirement in one job rather than sheet by sheet is therefore worth real money.
File Setup for Full-Sheet Printed Foam Core Boards
Large-format artwork has one requirement that A-size work does not: resolution has to survive at scale. Upload your file, or let our studio build the 8×4 plastic sign boards artwork from a brief.
- Size: 1220mm x 2440mm (122cm x 244cm / 48in x 96in)
- Resolution: 150 DPI at full size is sufficient for boards read from distance; 300 DPI where the panel will be viewed close up
- Bleed: 3–5mm on all four edges
- Colour Mode: CMYK
- Fonts: outlined or converted to curves
- File delivery via WeTransfer, Google Drive or Dropbox — full-sheet files routinely exceed email limits
A common shortcut works well here: build artwork at 25% scale (305mm x 610mm) at 300 DPI, which prints identically at full size and produces a far more manageable file. Our pre-press team checks every file manually before it reaches the press.
Delivery Options – Full-Sheet Foam Core Printing Near Me
- Standard delivery — 5 working days, no premium. Right for planned hoarding installs and scheduled refits.
- 72-hour express — three working days from artwork approval, the most economical express tier.
- 48-hour express — two working days, suited to replacement panels and short-notice site work.
- 24-hour express — printed and dispatched the same working day for next-working-day mainland UK delivery. Available on full sheets, since a single 32 sq ft board sits well inside the 81 sq ft threshold.
- Same-day collection — available on 122cm x 244cm sheets from Bolton and London, up to 64 sq ft in total (two full sheets). Daily capacity varies, so confirm on the calculator.
Every turnaround runs from artwork approval rather than order placement.
Finishing Options for Full-Sheet Foam Board Signage
Finishing matters more at full-sheet scale, because a 32 sq ft board carries far more wind load than a small panel and drilling one on site is awkward work.
- Clean straight-cut edges — every sheet is precision square-cut to full dimensions as standard.
- Eyelets, four corners — the standard specification for exterior full sheets, letting you tension the board evenly against hoarding, Heras fencing or scaffold. Four-point fixing is what stops a large panel lifting at the corners in wind.
- Eyelets, top only — for sheltered or interior positions where the board hangs freely.
- Drill holes, four corners — for permanent screw fixing onto timber hoarding, batten frames or masonry. Recommended over eyelets wherever the panel must sit flat and immobile.
- Drill holes, top only — for wall-hung interior panels not subject to wind loading.
- Matt or gloss lamination — matt kills glare on large indoor panels under downlighting; gloss deepens colour and adds a moisture and UV barrier on exterior sheets.
For exterior 122cm x 244cm boards we would specify 5mm with four-corner fixings as a matter of course.
What Full-Sheet Foam Board Is Used For
- Construction hoarding panels and site perimeter boards
- Shop fascia panels and retail frontage signage
- Exhibition stand walls and modular backdrop panels
- Event backdrops, photo walls and stage flats
- Large wayfinding and directional boards
- Property development and contractor identification boards
- Interior wall graphics and large-format branded panels
- Trade counter and showroom display walls
Why Printed Today for Full-Sheet PVC Foam Board Printing?
- Genuine single-piece 122cm x 244cm printing — no tiling, no joins, no colour shift across panels
- Both 5mm and 3mm available, so you pay for rigidity only where the application needs it
- Accurate colour and detail across the full 244cm span from expert foam core board printing
- Sharp per-sq-ft rates on large-format foam board signage, falling further with quantity
- Same-day collection from Bolton and London on full sheets, plus 24-hour express UK-wide
- Custom sizing and bulk hoarding runs handled as routine
Order your 8×4 printed foam core boards from Printed Today for full-sheet coverage that installs clean and reads sharp from any distance — fast, economical, and printed in one piece.
